Ramsey RPH-42.2 Winch (RPH-42.2)
Hydraulic Winches,
RMC:RPH-42.2
Please Call for Availability
800.877.0338
Description
- Foot mount or mid mount
- Manual or optional air operated free spool
- Winch reel-in rotation can be changed by reversing position of cartridge and plug in counterbalance valve
- Recommended cable 11 mm
- Available with a Blocked Clutch
- Motor spool (open center) directional control valve required
- Rated Line Pull 9,480 Lbs / 4,300 Kg / 42,2 Kn
- Gear Reduction 5.1:1
- Weight w/o Cable 110 Lbs / 49.9 Kg
- Brake Yes
- Cable None
- Drum Size (L x F x B) 9.75 x 8.75 x 3.94 In / 247.7 x 222.3 x 100.1 MM
- Cable Capacity 120 Ft / 36.6 M
- Recommend Cable Size 0.433 In / 11.0 MM
- 1st Layer Line Speed 32 Ft/Min / 9.7 M/Min
- Hydraulic Pressure Required 2,100 PSI (144.8 Bar)
